HOMAG BOF 211 VENTURE 12 XXL HOMAG BOF 211 VENTURE 12 XXL

Technische Daten

Working dimension X

6.175 mm

Working dimension Y

1.550 mm

Working dimension Z

300 mm

Independent Z-axes

2

Number of milling spindles

1

Milling spindle liquid-cooled

15 kW

Rotation speed max

24.000 rpm

Torque support

C-axis

5th axis

HSK-F63

Tool changer positions

30

Chain changer

3

Saw aggregate

9

Horizontal drilling spindles in X

2

Horizontal drilling spindles in Y

2

Lock recess milling aggregate

Unit, changeable, double-sided

Cantilever machine

Pod and rail table

HOMAG PM machine table

10

Positioning aid

2

Capacity vacuum pump

200 m³/h

Special workpiece clamping system

For windows

HOMAG 3-level clamping system

Safety mat

Chip conveyor

23 kW

Space requirement Length

10 m

Space requirement Width

5,5 m

Space requirement Height

2,95 m
