HOMAG LPP 307 /U/F HOMAG LPP 307 /U/F

Technische Daten

Working width

230 mm

Planing height

150 mm

Number of spindles

7

Bottom spindles

2

Right spindles

2

Spindles left

1

Spindles top

2

Spindle configuration

b-r-l-r-t-t-b

Spindle rotation speed max 1/min

8.000 rpm

Spindle diameter

40 mm

Feedrate max

24 m/min

Continuously variable feed

4 kW

Main motor power

7,5 kW

Chip rabbet cutter

Programmable controller

Surface of the machine table

Chromed

Infeed table length

2.500 mm

Table rollers

driven

Lubrication pump

manually

Pneumatic top pressure

Cardanic

Quick tool change

ProLock

CNC-axes

Yes
