CNC Laser Cutting Machine Amada FLC-3015 AJ-2000

Germany

Description

A comprehensive Amada CNC laser cutting system is available. Travel X/Y/Z: 3070mm/1550mm/100mm, max. table load: 920kg, positioning speed: 120m/min, simultaneous speed: 169m/min, acceleration: 30m/s², positioning accuracy: +/-0.01mm, position spread: +/-0.005mm, cutting capacity mild steel/aluminum/brass/copper: 16mm/10mm/8mm/5mm/4mm, machine weight: approx. 11000kg, control: AMNC 3i. Laser source: fiber laser, laser power: 2000W, wavelength: approx. 1µm, nozzle positions: 8, cooling system: WACS, conveyor belt direction: X. Including loading and unloading Profibus, water desalinator, water recooler, pallet changer and extraction system. Documentation available. On-site inspection is possible.
