Destacker Nutek NTM 220 DSXL-FW
Specifications
Germany
Description
A PCB destacker (PCB feeder) for the semiconductor industry is available. Transfer height: 950mm, transfer height adjustment: +/-25mm, belt speed: 12m/min, PCB edge support: 3mm, component clearance (bypass mode) top/bottom: 30mm/30mm, PCB thickness range: 0.6mm-4mm, PCB length range: 80mm-460mm, PCB width range: 75mm-460mm, max. PCB stacking height: 220mm, machine dimensions X/Y/Z: approx. 700mm/1000mm/1300mm, weight: approx. 200kg. Documentation available. On-site inspection is possible.
Additional Details
