Automatic Full Wrapping Machine Sollas 20 PLC

Germany

Description

Max. Wrapping material roll diameter: 320mm, inner core diameter: 70-83mm, processable materials: polypropylene (PP) and heat-sealable paper, processable film width: 50-420mm, max. cut-off length: 105-585mm, format dimensions length: 45-300mm, width: 40-200mm, height: 7-96mm, feed direction: conveyor belt HL (standard) from the left. Electrical system: 3x 400V/50Hz, with neutral conductor, power consumption: 3.5kW/h, compressed air requirement: 6bar at 4nl air per cycle, color: RAL 9010. Machine output: max. 50 cycles/minute (depending on product, dimensions and wrapping material), production output: approx. 40 cycles/minute (also depending), infeed/outfeed height: 900 ±20mm, changeover time: 15-20min, noise level: 78dB, weight: 950kg. With Siemens S7 ET 200 control system, monitoring of all electrical functions, incl. fault/diagnostic unit, Siemens TP177A touchscreen display, display of all machine and format data (formats A-B), frequency-controlled main motor for automatic or manual power adjustment to upstream or downstream systems, frequency-controlled conveyor belt: 1500x220mm, product infeed at an angle from the left with monitoring and CE mark. The machine sometimes has a fault in the rear area where the film is not folded correctly, the product is packaged, but the film can overhang at the fold seam. An on-site inspection is possible.
