Textile Laser Cutting Machine Sei Laser Mercury 2030 Conveyor 3

Germany

Description

Usable working area: 2000x3000mm, z-axis: 50mm, repeatability on the entire surface: ±0.05mm, X/Y/Z-addressable resolution: 0.001mm, max. acceleration: 15m/s², max. working speed in XY-axis: 2000mm/s, drives: X/Y-system with linear motors, Z-axis with servo motor. Laser protection class: Class 1, with cover, base body: stable, welded steel frame structure, axis system: X/ Y/ Z movement axes, drive: linear motor drive, contactless and low-wear, removal system: 2000mm extension, conveyor: Aluminum slats with servo motor drive, Pressure roller: for material, Laser source: CO2 laser 300W, closed and maintenance-free, Cooling: Closed cooling circuit with water recooler for laser, Cutting head: 5 inch, lens, cutting nozzle, cutting gas supply, Extraction: Extraction tray for small parts and dust, Software: CAM control software ICARO. Motorized brush width: 2000mm, SEI PC console: without computer, to be provided by the customer, Extraction unit: 2x extraction fans 5.5kW each, Scanner: Manual barcode scanner, Unwinding device: for material rolls with unwinding bar, Unwinding system: Connection available. The system was only installed and approved, series operation did not take place. On-site inspection is possible, documentation available.
